Pre-Lab: Standing Waves                   Name:



In the following problems, refer only the left most loops (as indicated in the lab manual) of a standing wave beginning at the bridge (count this left most node.)



1.     (½) What is the correct number of nodes if you count 3 antinodes from the left?

a.     2

b.    3

c.     4

d.    depends on arrangement




  1. (½) Referring to the previous problem, three antinodes represent how many loops?
    1. 2
    2. 3
    3. 4
    4. depends on the arrangement



3.    (1) In today’s lab you may suspend 0.102 N over the pulley at the edge of the table.  If the string has a m value of 2.56 x 10-3 g/cm, what is the velocity of this wave?

a.     40 m/s       (show work; include units)

b.    6.3 m/s

c.     400 m/s

d.    20 m/s









4.    (1)  In today’ lab, wavelength (l) is determined for various string tensions.  v = fl ; v = √FT/√μ

            f   l     =   √FT  /  √μ        (Hint:  check data sheet)







         y      =     m       x        +     b

Re-write the above equation in slope-intercept form (shown above) so that the slope is calculated by, D√FT / Dl.  Also which unknown is determined by this slope _______.



5.    (2) Using the following data and the known value of m = 2.56 x 10-3 g/cm, calculate the frequency of the string. (fill in table and show work for slope calc)

a.     50

b.    125

c.     195

d.    40

e.    14





n

(# of loops)

mass

(grams)

√Tension

(√Newton)

L

(cm)

Wavelength

(m)

1

629





l1 = 1.321

2

329





l2 = 1.011

5

91





l3 = 0.566
